Integrated Circuit #2
Figure 1 - Full-Focus Composite: This integrated circuit was imaged with a 100x air objective under standard halogen lighting. (Scroll for additional images of this sample.)
Figure 2 - Depth Colored: Depth information has been added to the image above through color with red corresponding to the higher points and blue the lower. This depth information provides layer separation crucial in circuit analysis. (Scroll for additional images of this sample.)
