Inkjet Ink on Paper

Figure 1 - Full-Focus Composite: This ink on paper was imaged with a 20x air objective under standard halogen lighting. (Scroll for additional images of this sample.)


Figure 2 - Contour Enhancement: The topography is enhanced in this image taken at 50x magnification under standard halogen lighting. Depth has been quantized and assigned color for more precise depth analysis. (Scroll for additional images of this sample.)


Figure 3 - SurfaceScope Capture: This 3D model of the above dataset allows rotation and tilting of the sample. (Scroll for additional images of this sample.)


Figure 4 - SurfaceScope Capture: This 3D model allows rotation and tilting of the sample. (Scroll for additional images of this sample.)


Figure 5 - Depth Colored: Depth information has been added through color with red corresponding to the higher points and blue the lower. (Scroll for additional images of this sample.)


Figure 6 - SurfaceScope Capture: This 3D model allows rotation and tilting of the sample. (Scroll for additional images of this sample.)
